Ultrasonic Cleaner

Industrial Ultrasonic Cleaner

We are one of the top manufacturers of Industrial Ultrasonic Cleaner. It uses ultrasound as well as cleaning solvents for the purpose of cleaning delicate items. Considering the material to be cleaned and nature of containments present on it, the solvent type can be selected. This type of cleaner is commonly used in jewelry workshops, watch shops and electronic repairing units. Industrial Ultrasonic Cleaner is instrumental in minimizing the down time as well as labor for the purpose of cleaning. It also does not causes any type of pollution.

We also offer ultrasonic with higher volume size tank and generators. These are used in industries for cleaning purposes. The sizes are standard but we do provide customized size as per the requirements / application.

Requirement to choose a ultrasonic cleaner :

• Tank Size required
• The material type that needs to be clean
• Ultrasonic power required to carry out cleaning.
• Material to be cleaned, viz, metal, glass, etc.
• Frequency required in generator.
• Process i.e, Cooling, Heating, filtration, hot air dryer etc.

After getting these points and analyzing the customers requirements, we design the ultrasonic cleaner accordingly, that suits the customer needs better.

Ultrasonic Immersible Transducers

• Enable user to add ultrasonic advantage to your existing cleaning application. It can be installed on the bottom, surface, the side or the top of cleaning tank according to different need.
• Entire stainless steel 316 L structure: acid proof and bears the alkali, and is durable.
• There are many ways to install the ultrasonic immersible transducer: set on the bottom, surface, the side or the top of cleaning tank according to needs.
• We can design and customize various ultrasonic immersible transducer based on requirements.

Features :

• More Even Cavitations, yet cleaning
• High Intensity Ultrasonic Design
• Efficient Design Yields longer life.

Ultrasonic Bath -Digital ( 250 watt x 4 Modules)

• Capacity : 30 Litres
• Wattage : 1000 ( 250 watt x 4 Modules)
• Frequency : 23 to 37 KHz
• Tank : SS304, 16 Gauge
• Timer : 0 - 999 Seconds
• Pocket Heater : 1500 Watts
• Control : PID with SSR switching
• Sensor : RTD PT 100
• Meter : Online Frequency meter
• Indicator : Overload Protection/Circuit Failure
• Fuse : 5 Amp
• Supply : 230 VAC, 50 Hz

BIONS Ultrasonicator Bath with cooling

• Tank Size : 600 x 900 x 900 mm (LxWxH)
• Capacity : 500 Litre (Approx)
• MOC : Tank SS 304
• Outer : With heavy duty MS pipe with powder coating
• Sensor : Provided with water level sensor with controller
• Generator : Separate cabinet with all controls
• Power : 4000 Watts
• Frequency : 25 KHz -/+ 3KHz
• Timer : Digital timer with 0-999 Minutes
• Driver : Solid State Circuit
• Cabinet : MS with powder coating
• Overflow gutter for oil separator with solvent recirculation through filter.
• Cooling coils for temperature control with Chiller
• Provided with castor wheels for easy movement.
• Supply : 220 V AC , 50 Hz, Single Phase
